DW130NC Big Diameter Pipe Bending Machine
Categories
Other pipe processing machines
Brand
TELHOO bending machine
Model
DW130NC
Condition
New
Machine Type
Pipe and Tube Bending Machine
Raw Material
Pipe
Material / Metal Processed
carbon steel, stainless steel, copper, aluminium, galvanized, etc.
Power
Hydraulic
Automation
Manual
Certificate
CE
After-sales Service Provided
Engineers available to service machinery overseas
big diameter pipe bending machine
big diameter pipe bending machine
FOB port
Shanghai, China
Terms of Payment
L/C, T/T, Western Union, MoneyGram
Download DOC

Update Time
2017-05-18


Detail Information
DW130NC big diameter pipe bending machine
Adapted material:steel pipe, stainless steel, copper pipe, aluminum pipe;
Recommended application industry:
automobile fittings ( oil pipe for brake, muffler, seats), motorcycle, healthy equipment, air-conditioning,bicycle, steel furniture, sanitary wares and so on.
Main specification
1. NC control unit
2. Direct acting hydraulic clamping
3. Manual feeding and bending
4. Can make 2-dimensional elbow bend
5. Easy operaton interface and easy data input
6. Large program storage capacity up to 16 units
7. Automatically lock angle, angle changing is controlled by coder
8. High bending accuracy
9. Self diagnosis and error messages
10. Optional boost facility
11. Fit for carbon steel pipe, stainless steel pipe, alloy steel pipe, aluminium pipe, copper pipe, etc.
12. Bending diameter of pipe: 0.5-8 inch
13. Bending radius: 175-550mm
14. Max bending angle: 185 degrees
Technical parameter

Specification/Model
Unit
DW115NC
Remark
Max bending capability
mm
Φ115.8×6.0t

1. The Minimum bending radius based on the pipe diameter
2.The Max bending radius can according to the customer’s requirement
3.The Max length of mandrel can according to customer’s requirement

Max bending radius
mm
R550
Min bending radius
mm
R50
Max bending angle
Degree
185
Max effective distance of mandrel
mm
4200
Control System

NC Control
Max elbow bend pipe
Unit
16
Max storable sections
Unit
16×16
Motor power
KW
22
Max. Hydraulic Pressure
Mpa
14
Hydraulic System Control

Electromagnetic Valve
Oil Tank Capacity
L
120
Size
Cm
520×180×140
Weight of Machine
Kg
≈8000
