Production describle:
0660D010BN3HC belongs to the red series of hydac Company, which is installed in the pressure pipeline, and belongs to the filter element of medium and low pressure filter. It is used in the oil circuit of hydraulic system to remove the worn metal powder and other mechanical impurities in the hydraulic system to keep the oil circuit clean. It can prolong the life of hydraulic system. It has a high filtration ratio and a high value of stability, and the high value is almost unchanged in the range of rated pressure.
Characteristics and advantages:
At the joint of corrugated filter material, v-shaped bonding process is adopted, the inherent strength of the material and the strong structural support on both sides of the filter element are adopted. The pressure difference is allowed to fluctuate in a wide range Can be used according to different requirements, can use stainless steel mesh, sintered felt filter and so on. The filtering accuracy can be selected from 1,3 ,6 10,12,22,25 microns and so on.
With reasonable combination, the filtration effect is better, high pressure collapsibility and high circulation. The filter element of 0660d010bn3hc series instead of hydac has the same size and can completely replace the original product and achieve the original filter effect.
Technical Data:
Filter element type
High efficiency folding filter
Filter medium
Resin consolidated glass fiber high efficiency filter material mixed with Wire mesh
Glass fiber filter material
1, 3, 5, 5, 7, 10, 12, 22 microns available
Internal support and end cover material
Metallized tin / reinforced nylon / stainless steel
Working temperature
-20℃~110℃
Working pressure
20Bar~210Bar
FST- RP-0060D010BN3HC filter element instead of HYDAC hydraulic oil filter element execution standard:
ISO2491 filter-rupture resistance experiment:
The test of resistance to rupture of filter element belongs to the strength test of the filter element itself. The filter element is generally subjected to external force by the pressure difference limit after carrying the dirt in the filter shell. The inner skeleton is the main support of the filter layer under the limit pressure difference of the filter element, and the collapse of the skeleton will lead to the collapse of the filter layer.
ISO2492 filter element structural integrity experiment:
The significance of the requirement of the integrity of the filter element structure, the filter material is very good, the filter material is broken or made incomplete in the process of making the filter element, the incomplete phenomenon mainly manifests in: the filter material is damaged, the end cover is not glued strictly, the filter material butt joint is not strict and solid. It will greatly affect the original filtering accuracy.
ISO2493 filter element the compatibility betwee material and liquid experiment:
The compatibility test between filter element and working fluid is mainly a validation test of the properties of raw materials used in the process of making filter elements, such as compatibility with petroleum, water diol, water-oil emulsion and liquid with high water content. PTFE seals are standard configurations and can be used in conjunction with industrial phosphate, diesters and specific synthetic materials.
ISO3726 filter element experimental method of the end load:
The end load test of the filter element mainly tests the ability of bearing the axial mounting force, the strength, the axial load, the flattening strength and so on.
ISO3724 filter element the determination of fatigue characteristics:
The test of the fatigue characteristics of the filter element is the test of the life of the filter element. The filter element works in the hydraulic system, withstanding the reciprocating and alternating fluid flow of the system and the pressure impact of the working flow. Under this impact, if the filter element has accumulated pollutants and established a greater pressure difference, then the pressure of the filter layer withstanding the fluid flow will be greater.
ISO3968 filter element determination of flow characteristics and the pressure difference:
The pressure drop flow characteristic is usually an assessment of the filter, but in fact, it mainly evaluates the flow rate and resistance of the filter core. Of course, in the design of filter assembly, there are flow and bypass problems in the channel design of the shell. But after all, it is not the main problem, the main problem is the filter, so the standard mainly checks the filter, not the filter.
The replacement of HYDAC company hydraulic filter type Series: (FST- RP-xxxxxxxx)
0660D020BN3H
0660D020BH3HC
0660D010BN3HC
0660D010BH3HC
0660D005BN3HC
0660D005BH3HC
0660D003BN3HC
0660D003BH3HC
Replacement of HYDAC 0660D010BN3HC ElementHYDAC 0660D010BN3HC Filter ElementReplacement of HYDAC 0660D010BN3HC0660D010BN3HC Oil Filter Element
