Hydraulic 7 Roller Pipe Bending Machine For Big Radius
Categories
Roller pipe bending machine
Brand
TELHOO bending machine
Model
GW50
Condition
New
Machine Type
Roller-Bending Machine
Raw Material
Sheet / Plate Rolling
Material / Metal Processed
Carbon Steel
Power
Hydraulic
Automation
Automatic
Extra Services
Machining
Certification
ISO 9001:2000
After-sales Service Provided
Engineers available to service machinery overseas
Roller
3 or 7
FOB port
Shanghai, China
Terms of Payment
L/C, T/T

Hydraulic 7 roller pipe bending machine for big radius

Adapted material:steel pipe, stainless steel, copper pipe, aluminum pipe or profile.
Mechanical properties:
1.full-automatic transmission, compact structure, high reliability;
2.Three-roller transmission is not easy to slide. The thin-wall material also may be bended.
3.The rollers on both sides are distributed asymmetrically, reducing linear part.
4.Both the sides of the side roller can be used for feeding workpiece.
5.The double-footplate switch is equipped with emergent stopping system for operating conveniently.
6.This machine drives stably. Only regulate the side roller up and down can get round, arc or spirality of different curvatures.
7.If change mould’s shape, various metal shaped materials can be processed, like angle iron, flat steel, round steel or other special shaped material
8.It avoids the shortcomings of making super large tube bending mould while bending the large-radius shaped material, which is a necessary complementarity that series single-head, double-head tube benders can not reach.
9.Being of high speed and high benefit, this machine is adapted for middle or large batches production.
Technical parameter:
Properties
Spec.
Max diameter of bended tube
Φ50×1.5
Min. Bending diameter
Φ280
Rolling speed
4m/min
Diameter of mould
Φ250
Motor power
4kw
Weight
1200kg
