In Stock QZ-2CS Gasoline Engine Rock Core Drilling Rig

1.Brief introductions of QZ-2CS drilling rig
QZ-2CS type gasoline engine portable sampling drill is used for geological industrial and civil buildings, bridges, railway, highway, hydro power industry survey, geophysical exploration, advanced drilling and grouting hole drilling.
QZ-2CS drilling rig has the following features: compact structure, small volume, light weight, two gears, easy to move.
2.Specifications of QZ-2CS drilling rig
QZ-2CS drilling rig
End hole diameter (mm) 32-91


Drilling depth（m） soil 91：10-15m
stone 91：5-10m
stone 75：10-15m
stone 60：15-20m
stone 46：20-30m
Drilling pipe diameter(mm) 30
Gasoline engine horse power(hp） 6(4.5kw)
displacement（cc） 224
Dimension（l*w*h） 600*450*1900
Weight（kg） 95
3.Configuration list of QZ-2CS
Item Parameter Unit Quantity
Gasoline core drilling rig QZ-2CS set 1
Drilling pipe 30*1500 pc 6
Drilling pipe 30*800 pc 14
Pipe joint 38 pc 20
Reducing nipple 58/38 pc 2
Core barrel 58*800 pc 1
Core barrel 58*1500 pc 1
Alloy bit 60 pc 1
Diamond bit 60 pc 1
Reducing nipple 73/38 pc 2
Core barrel 73*800 pc 1
Alloy bit 75 pc 1
Diamond bit 75 pc 1
Three-wing bit 75 pc 1
Safety clamp pc 1
Water seal Y 30*50*10 pc 4
Oil seal 30*50*10 pc 1
Pipe wrench 18 pc 2
Monkey wrench pc 1
Shaft snap ring clamp pc 1
Hole snap ring clamp pc 1
Clamp pc 1
Cross screwdriver pc 1
Hex wrench pc 1
Control wheel pc 1
If you need a wooden base, a high pressure pump and a high pressure water pipe, please specify.
